Faxon 6MM ARC 20" Heavy Fluted Match Series Barrel

Faxon 6MM ARC 20″ Heavy Fluted Match Series Barrel

The Faxon 6MM ARC 20″ Heavy Fluted Match Series Barrel is designed for precision performance in long-range AR builds. Crafted in-house from stress-relieved 416R stainless steel, this barrel features aggressive straight fluting for reduced weight and enhanced cooling—delivering durability without compromising accuracy.

Featuring 5R rifling and an 11-degree target crown, this barrel enhances bullet stability, minimizes jacket deformation, and promotes higher velocities. The QPQ nitride finish and Nickel Teflon-coated M4 feed ramp extension provide superior corrosion resistance, extended lifespan, and smooth feeding under hard use. This model includes a rifle-length gas system and a .750 gas block journal, making it ideal for precision applications.

Each Faxon Match Series barrel is MPI inspected and individually headspace checked using precision custom hardened gauges. The result is a barrel you can count on for dependable, repeatable accuracy from shot to shot—even in high-pressure or competition environments.

• 5R Rifling – Improves Accuracy & Barrel Life
• 11-Degree Target Crown – Enhances Precision
• 416R Stainless Steel – Match-Grade Quality
• QPQ Nitride Finish – Corrosion Resistant
• Aggressive Straight Fluting – Reduces Weight
• Nickel Teflon Coated M4 Feed Ramp Extension
• Rifle-Length Gas System – Optimized for Long-Range Use

Technical Specifications:

• Caliber: 6MM ARC
• Barrel Length: 20″
• Gas System: Rifle-Length
• Material: 416R Stainless Steel
• Profile: Heavy, Fluted
• Rifling: 5R
• Crown: 11-Degree Target Crown
• Finish: QPQ Nitride
• Gas Block Diameter: 0.750″
• Extension: Nickel Teflon Coated M4 Feed Ramp
• Inspected: MPI & Headspace Checked

If you are new to building a custom AR or have any questions about the Faxon 6MM ARC 20″ Heavy Fluted Match Series Barrel, we are always here to help!
